Led Screens

With the gaining popularity of LED screens, it can be difficult to know which one is right for your ministry, venue, or touring needs. At JAH, we hope to make this process easier for you by providing LED screens with some of the highest standards in the industry. We go through extreme measure to make sure our screens meet the demands of the road, while maintaining the consistency required for permanent facilities. Our screens are great for any venue or event, however they are specifically optimized for on camera performance.

JE2.97

Product Specifications

JE Series is built with value engineering in mind. We retain some of our most important features at an incredibly low price. Although it is our economy solution, we were sure to include Smart Module Calibration Technology, Novastar A8s receiving cards for 14 bit grey scale, front serviceable modules, and FCC and ETL certifications.

$1197.99

  • IP Rating IP30
  • Working Environment Humidity 10%~90%
  • Working Environment Temperature 0C~+50C (32F ~ 122F)
  • Max Heat Load 181 BTU/Hr
  • Max Power Consumption 105W
  • Average Power Consumption 53W
  • Power Supply 100-240V 50/60Hz
  • Power Connection Powercon In + Out
  • Weight 8.8kg (19.5lbs
  • Gap Between Panels < 0.2mm
  • Module Dimensions 500mm x 250mm (19.7in x 9.8in)
  • Panel Dimensions 500mm x 500mm x 88mm (19.7in x 19.7in x 3.5in)
  • Frame Material Die Cast Aluminum
  • Specifications:
  • Receiving Card Novastar A8s
  • Exchange Frame Rate ≤ 60 frames/second
  • Brightness Adjustment 256 grade automatic, 8 grade manual
  • Grey Scale 14 bit
  • Refresh Rate ≤ 3840Hz
  • IC FM6565
  • Data In/Out Network in + Out
  • Drive Mode 1/28
  • Control:
  • LED Lifespan > 100,000 Hrs
  • Module Configuration 2 pcs
  • Color Temperature 6500k - 9000k
  • Contrast Ratio 3600:1
  • Vertical Viewing Angle > 140
  • Horizontal Viewing Angle > 140
  • Best Viewing Distance > 4m ( ft)
  • Pixel Density 28,224 Pixels Per Panel
  • Resolution 168 x 168
  • Brightness 1000nit
  • Pixel Configuration SMD2020 Blackface
  • Pixel Pitch 2.97mm
  • Optics:
